Print selected text pages to PDF with Python, selpg and xtopdf on Linux

without comments

By Vasudev Ram



In a recent blog post, titled My IBM developerWorks article, I talked about a tutorial that I had written for IBM developerWorks a while ago. The tutorial showed some of the recommended techniques and practices to follow when writing a Linux command-line utility that is intended for production use, and how to write it in such a way that it can easily cooperate with existing UNIX command-line tools, when used in a UNIX command pipeline.

This ability of properly written command-line tools to cooperate with each other when used in a pipeline, is, as I said in that IBM article, one of the keys to the power of Linux (and UNIX) as a development environment. (See the classic book The UNIX Programming Environment, for much more on this topic.)

The utility I wrote and discussed (in that IBM article), called selpg (for SELect PaGes), allows the user to select a specified range of pages from a text file. At the end of the aforementioned blog post, I had said that I would show some practical uses of the selpg utility later. I describe one such use case below, involving a combination of selpg and my xtopdf toolkit), which is a Python library for PDF creation.

(The xtopdf toolkit contains a PDF creation library, and also includes some sample applications that show how to use the library to create PDF output in various ways, and from various input sources, which is why I tend to call xtopdf a toolkit instead of just a library.

I had written one such application of xtopdf a while ago, called StdinToPDF(.py) (for standard input to PDF). I blogged about it at the time, here:

[xtopdf] PDFWriter can create PDF from standard input. (PDFWriter is a module of xtopdf, which provides the core PDF creation functionality.)

The selpg utility can be used with StdinToPDF, in a pipeline, to select a range of pages (by starting and ending page numbers) from a (possibly large) text file, and write only those selected pages to a PDF file. Here is an example of how to do that:

First, build the selpg utility from source, for your Linux OS. selpg is only meant to work on Linux, since it uses some Linux C standard library functions, such as from stdio.h, and popen(); but you can try to run it on Windows (at your own risk), since Windows does have (had?) a POSIX subsystem, from Windows NT onward. I have used it in the past. (Update: I checked - according to this section of the Wikipedia article about POSIX, Windows may have had POSIX support only from Windows NT up to Windows 2000.) Anyway, to build selpg on Linux, follow the steps below (the $ sign is the shell prompt and not to be typed):

1. Download the source code from the sources section of the selpg project repository on Bitbucket.

Download all of these files: makefile, mk, selpg.c and showsyserr.c .

2. Make the (shell script) file mk executable, with the command:
$ chmod u+x mk
3. Then run the file mk, with:
$ ./mk
That will run the makefile that builds the selpg executable using the C compiler on your Linux box. The C compiler (invoked as cc or gcc) is installed on most mainstream Linux distributions. If it is not, you will need to install it from the repository for your Linux distribution. Sometimes only a minimal version of a C compiler is installed, which is only enough to (re)compile the kernel after making kernel parameter changes, such as for performance tuning. Consult your local Linux expert for help if such is the case.

3. Now make the file selpg executable, with the command:
$ chmod u+x selpg
4. (Optional) You can check the usage of selpg by reading the IBM tutorial article and/or running selpg without any command-line arguments:
$ ./selpg
which will show a usage message.

6. (Optional) You can run selpg a few times with some text file(s) as input, and different values for the -s and -e command-line options, to get a feel for how it works.

Now download xtopdf (which includes StdinToPDF) from here:

xtopdf on Bitbucket.

To install it, follow the steps given in this post:

Guide to installing and using xtopdf, including creating simple PDF e-books

That post was written a while ago, when xtopdf was hosted on SourceForge. So you need to make one change to the instructions given in that guide: instead of downloading xtopdf from SourceForge, as stated in Step 5 of the guide, get it from the xtopdf Bitbucket link I gave above.

(To make xtopdf work, you also have to install ReportLab, which xtopdf depends uses internally; the steps for that are given in my xtopdf installation guide linked above, or you can also look at the instructions in the ReportLab distribution. It is easy, just a couple of steps - download, unzip, configure a setting or two.)

Once you have both selpg and xtopdf installed, you can use selpg and StdinToPDF together. Here is an example run, to select only pages 2 through 4 from an input text file:

I wrote a simple Python program, gen_selpg_test_file,py, to create a text file that can be used to test the selpg and StdinToPDf programs together.

Here is an excerpt of the core logic of gen_selpg_test_file.py, omitting argument and error handling for brevity (I have those in the actual code):

# Generate the test file with the given filename and number of lines of text.
try:
out_fil = open(out_filename, "w")
except IOError as ioe:
sys.stderr.write("Error: Could not open output file {}.\n".format(out_filename))
sys.exit(1)
for line_num in range(1, num_lines + 1):
line = "Line #" + str(line_num).zfill(10) + "\n"
out_fil.write(line)
out_fil.close()
I ran it like this:
$ python gen_selpg_test_file.py selpg_test_file_1000.txt 1000
to generate a text file with 1000 lines, in the file selpg_test_file_1000.txt .

Then I could run the pipeline using selpg and StdinToPDF, as described above:
$ ./selpg -s2 -e4 selpg_test_file_1000.txt | python StdinToPDF.py p2-p4.pdf
This command extracts only the specifed pages (2 to 4) from the input file, and pipes them to StdinToPDF, which converts those pages only, to PDF, in the filename specified at the end of the command.

After doing the above, you can open the file p2_p4.pdf in your favorite PDF reader (Evince is one PDF reader for Linux), to confirm that it contains all (and only) the lines from page 2 to 4 of the input file selpg_test_file_1000.txt (considering 72 lines per page, which is the default that selpg uses).

Read the IBM article to see how that default can be changed - to either another number of lines per page, e.g. 66 or 80 or whatever, or to specify form feeds (ASCII code 12) as the page delimiter. Form feeds are often used as a page delimiter in text file reports generated by programs, when the reports are destined for a printer, since the form feed character causes the printer to advance the print head to the top of the next page/form (that's how the character got its name).

Though this post seemed long, note that a lot it was either background information or instructions on how to build selpg and install xtopdf. Those are both one time jobs. Once those are done, you can select the needed pages from any text file and print them to PDF with a single command-line, as shown in the last command above.

This is useful when you printed the entire file earlier, and some pages didn't print properly because the printer jammed. Just use selpg with xtopdf to print only the needed pages again.



The image above is from the Wikipedia article on Printing, and titled:

Jikji, "Selected Teachings of Buddhist Sages and Son Masters" from Korea, the earliest known book printed with movable metal type, 1377. Bibliothèque Nationale de France, Paris

- Enjoy.

- Vasudev Ram - Dancing Bison Enterprises

Click here to get email about new products from Vasudev Ram.

Contact Page

Google Inbox launched, successor to Gmail

without comments

By Vasudev Ram


Google has launched a new email product called Google Inbox.

Saw this via Hacker News:

A post about Google Inbox on the official Google blog:

An inbox that works for you.

Hacker News thread about Google Inbox.

Google is going to roll out Inbox in stages to various sets of people. If you want to get an invitation to it, you can email them at inbox@google.com. I did it. Once I get invited, if I find Google Inbox useful or interesting, I will write a post about it.

Meanwhile, here are a few features of Google Inbox mentioned in the official Google blog post:

Bundles (of emails) - like categories that they had before in Gmail.

Highlights - key information from important messages.

Reminders, Assists, and Snoozes.

Assist - if you send a reminder to the hardware store, Assist will tell you its number and if it's open.

Snooze lets you snooze away emails and reminders, until a later time or until you reach another place, like your office.

Interestingly, Google seems to have made a somewhat poor choice of name for the product, again (after doing it with "Go" for the Go language), since in both cases, the word is very common and generic ("inbox" and "Go"), so it will be difficult to search for (even using Google, ironically).

Of course, there are workarounds, like using "golang" instead of "Go", and I'm guessing "Google Inbox" instead of just "Inbox", but those won't work as well as having a more unique name. I just did a Google search for the word "inbox", though, and www.google.com/inbox/ was the first hit.

- Vasudev Ram - Dancing Bison Enterprises

Click here to signup for email notifications about new products and services from Vasudev Ram.

Contact Page

Written by Vasudev Ram

October 22nd, 2014 at 4:12 pm

Published my first presentation on SpeakerDeck – using Python

without comments

By Vasudev Ram



SpeakerDeck is an online presentation service roughly like SlideShare. SpeakerDeck seems to have been created by Github Inc.

I just published my first presentation on SpeakerDeck. It is a quickstart tutorial for the vi editor. Note: vi, not vim. I had written the tutorial some years ago, when vim was not so widely used, and vi was the most common text editor on Unix systems.

About the tutorial:

I first wrote this vi quickstart tutorial for some friends at a company where I worked. They were Windows and network system administrators without prior Unix experience, and had been tasked with managing some Unix servers that the company had bought for client work. Since I had a Unix background, they asked me to create a quick tutorial on vi for them, which I did.

Later on, after learning the basics of vi from it, and spending some days using vi to edit Unix configuration files, write small shell scripts, etc., they told me that they had found the tutorial useful in getting up to speed on vi quickly.

So, some time later, I thought of publishing it, and sent an article proposal to Linux For You magazine (an Indian print magazine about Linux and open source software). The proposal was accepted and the article was published.

About generating the tutorial as PDF and uploading it to SpeakerDeck:

The original vi quickstart tutorial was in text format. Last year I wrote XMLtoPDFBook (as an application of xtopdf, my Python toolkit for PDF creation), which allows the user to create simple PDF e-books from XML files. So I converted the vi tutorial to XML format (*) and used it to test XMLtoPDFBook. I therefore had the tutorial available in PDF format.

(*) All you have to do for that - i.e. to convert a text file to the XML format supported by XMLtoPDFBook - is to insert each chapter's text as a <chapter> element in the XML file. Then give the XML file as the input to XMLtoPDFBook, and you're done.

SpeakerDeck requires that presentations be uploaded in PDF format. It then converts them to slides. So I thought it would be a good test of SpeakerDeck and/or xtopdf, to upload this PDF generated by xtopdf to SpeakerDeck, and see how the result turned out. I did that today. Then I viewed the resulting SpeakerDeck presentation. It was good to see that the conversion turned out well, AFAICT. All pages seem to have got converted correctly into slides.

The presentation can be viewed here:

A vi quickstart tutorial

If you prefer plain text to presentations, you can read the vi quickstart tutorial here.

- Vasudev Ram - Dancing Bison Enterprises

Click here to signup for email notifications about new products and services from Vasudev Ram.

Contact Page

Written by Vasudev Ram

October 19th, 2014 at 1:30 pm

Bad Voltage Season 1 Episode 27: Buffalo Wild Wings Dollars

without comments

Bryan Lunduke, Jono Bacon, Stuart Langridge, and myself present Bad Voltage, in which there is only one. We also discuss:

  • Would it be bad if the open source desktop fails to go mainstream? Is not wanting large public success just elitism? Or is this the year that we pronounce it isn’t and never will be “the year of the Linux desktop”, and is that a terrible thing? (3.14)
  • We review the Canon HF-R500 digital camcorder (27.10)
  • Why do film and TV scripts get technology wrong when it would be just as easy to get it right? Should we be amused or annoyed by technobabble? (39.45)
  • Should programming be part of a school curriculum, not to program specifically but to teach skills of logically constructing an argument and meta-skills of thinking “how to think”? (50.58)

Listen to 1×27: Buffalo Wild Wings Dollars

As mentioned here, Bad Voltage is a new project I’m proud to be a part of. From the Bad Voltage site: Every two weeks Bad Voltage delivers an amusing take on technology, Open Source, politics, music, and anything else we think is interesting, as well as interviews and reviews. Do note that Bad Voltage is in no way related to LinuxQuestions.org, and unlike LQ it will be decidedly NSFW. That said, head over to the Bad Voltage website, take a listen and let us know what you think.

–jeremy


Written by jeremy

October 18th, 2014 at 9:30 am

Posted in Bad Voltage

iceweasel fails to laucnh after kernel upgrade

without comments

If after upgrading to kernel version 16 or above ,iceweasel fails to launch, try launching it from the command line using the command



If you see the following error in the terminal



It means that the iceweasel needs to be upgraded. We can do that easily from the package manager. Just open the package manager search for the package iceweasel. Right click on the package and selcet "mark for upgrade" and then click on apply.

Once iceweasel is upgraded the above error should not come.


Written by Tux Think

October 17th, 2014 at 7:01 am

Posted in Linux,Trouble Shoot

How to check for SSL POODLE / SSLv3 bug? How to fix Nginx?

without comments

Google has just disclosed SSL POODLE vulnerability which is a design flaw in SSLv3. Since it is a design flaw in the protocol itself and not an implementation bug, there will be no patches. Only way to mitigate this is to disable SSLv3 in your web server or application using SSL.

How to test for SSL POODLE vulnerability?
$ openssl s_client -connect google.com:443 -ssl3
If there is a handshake failure then the server is not supporting SSLv3 and it is secure from this vulnerability. Otherwise it is required to disable SSLv3 support.

How to disable the SSLv3 support on Nginx?
In nginx configuration, just after the "ssl on;" line, add the following to allow only TLS protocols:
ssl_protocols TLSv1.2 TLSv1.1 TLSv1;

Hacker News: Discuss and upvote on Hacker News.

Written by Aditya Patawari

October 15th, 2014 at 4:51 am

Let’s do some magic with Python

without comments

By Vasudev Ram



python-magic is a Python wrapper for the libmagic C library which allows you to detect the type of a file by reading and deciphering the initial part of its contents, and/or by using the magic number database for file types. The Unix command called file uses libmagic internally. When you give the command:
$ file *
at a Unix command prompt, it gives you output showing its guess (using libmagic) as to the type of each file in the current directory (because the * is a wildcard that matches all the filenames in the current directory).

For example, if there are 10 files in the directory, it may detect and tell you that the 1st file is a text file, the 2nd is the source code of a C program, the 3rd is the object (compiled) code of that C program, the 4th is a PDF file, the 5th is an HTML file, the 6th is a Linux executable (which may be the end result of linking the object code mentioned earlier with some standard libraries), and so on.

Here is a simple example showing the use of the python-magic library:
>>> import magic
>>> magic.from_file("testdata/test.pdf")
'PDF document, version 1.2'
>>> magic.from_buffer(open("testdata/test.pdf").read(1024))
'PDF document, version 1.2'
>>> magic.from_file("testdata/test.pdf", mime=True)
'application/pdf'
Here is an example program that reads the list of files in the current directory, and for each file, prints the filename, the file type and the file's MIME type.
(I used the term MIME type loosely; it should really be called Internet media type.)

import os
import magic
from magic import from_file

def do_magic(filename):
file_type = from_file(filename)
mime_type = from_file(filename, mime=True)
print "{}: {} | {}".format(filename, file_type, mime_type)

print "filename: file_type | mime_type"
for filename in os.listdir('.'):
do_magic(filename)
Example program output:
filename: file_type | mime_type
awk: directory | inode/directory
awk.tar: POSIX tar archive (GNU) | application/x-tar
echoer: ASCII text | text/plain
echoer.sh: ASCII text | text/plain
pdf_cherry.py.pdf: PDF document, version 1.3 | application/pdf
prog1.c: ASCII C program text | text/x-c
prog1.o: ELF 32-bit LSB relocatable, Intel 80386, version 1 (SYSV), not stripped | application/x-object
prog2.c: ASCII C program text | text/x-c
prog2.o: ELF 32-bit LSB relocatable, Intel 80386, version 1 (SYSV), stripped | application/x-object
reportlab-1.21.1: directory | inode/directory
selpg: directory | inode/directory
test1.tar.gz: gzip compressed data, was "test1.tar", from Unix, last modified: Mon Oct 13 19:50:01 2014 | application/x-gzip
test_python_magic.py: Python script, ASCII text executable | text/x-python
test_python_magic2.py: Python script, ASCII text executable | text/x-python
text_file.txt: ASCII text | text/plain
tpm.out: ASCII text | text/plain
tpm2.out: empty | inode/x-empty
xtopdf: directory | inode/directory
So the python-magic library can be useful, since it allows us to detect the type of a file (correctly most of the time) from within our Python code, and then do something meaningful with that information.

For example, a program that reads all the files under a directory tree, can be made to do the right kind of processing with each type of file, based on the file type it detects using python-magic.

Abracadabra!

- Vasudev Ram - Dancing Bison Enterprises

Click here to signup for email notifications about new products and services from Vasudev Ram.

Contact Page

Written by Vasudev Ram

October 14th, 2014 at 5:29 pm

A Quick and Practical Reference for tcpdump

without comments

When it comes to tcpdump most admins fall into two categories; they either know tcpdump and all of its flags like the back of their hand, or they kind of know it but need to use a reference for anything outside of the basic usage. The reason for this is because tcpdump is a pretty advanced command and it is pretty easy to get into the depths of how networking works when using it.

For today's article I wanted to create a quick but practical reference for tcpdump. I will cover the basics as well as some of the more advanced usage. I am sure I will most likely leave out some cool commands so if you want to add anything please feel free to drop it into the comments section.

Before we get too far into the weeds, it is probably best to cover what tcpdump is used for. The command tcpdump is used to create "dumps" or "traces" of network traffic. It allows you to look at what is happening on the network and really can be useful for troubleshooting many types of issues including issues that aren't due to network communications. Outside of network issues I use tcpdump to troubleshoot application issues all the time; if you ever have two applications that don't seem to be working well together, tcpdump is a great way to see what is happening. This is especially true if the traffic is not encrypted as tcpdump can be used to capture and read packet data as well.

The Basics

The first thing to cover with tcpdump is what flags to use. In this section I am going to cover the most basic flags that can be used in most situations.

Don't translate hostnames, ports, etc

# tcpdump -n

By default tcpdump will try to lookup and translate hostnames and ports.

# tcpdump
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
16:15:05.051896 IP blog.ssh > 10.0.3.1.32855: Flags [P.], seq 2546456553:2546456749, ack 1824683693, win 355, options [nop,nop,TS val 620879437 ecr 620879348], length 196

You can turn this off by using the -n flag. Personally, I always use this flag as the hostname and port translation usually annoys me because I tend to work from IP addresses rather than hostnames. However, knowing that you can have tcpdump translate or not translate these are useful; as there are times where knowing what server the source traffic is coming from is important.

# tcpdump -n
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
16:23:47.934665 IP 10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], seq 2546457621:2546457817, ack 1824684201, win 355, options [nop,nop,TS val 621010158 ecr 621010055], length 196

Adding verbosity

# tcpdump -v

By adding a simple -v the output will start including a bit more such as the ttl, total length and options in an the IP packets.

# tcpdump
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
16:15:05.051896 IP blog.ssh > 10.0.3.1.32855: Flags [P.], seq 2546456553:2546456749, ack 1824683693, win 355, options [nop,nop,TS val 620879437 ecr 620879348], length 196

tcpdump has three verbosity levels, you can add more verbosity by adding additional v's to the command line flags. In general whenever I am using tcpdump I tend to use the highest verbosity, as I like having everything visible just in case I need it.

# tcpdump -vvv -c 1
tcpdump: listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
16:36:13.873456 IP (tos 0x10, ttl 64, id 121, offset 0, flags [DF], proto TCP (6), length 184)
    blog.ssh > 10.0.3.1.32855: Flags [P.], cksum 0x1ba1 (incorrect -> 0x0dfd), seq 2546458841:2546458973, ack 1824684869, win 355, options [nop,nop,TS val 621196643 ecr 621196379], length 132

Specifying an Interface

# tcpdump -i eth0

By default when you run tcpdump without specifying an interface it will choose the lowest numbered interface, usually this is eth0 however that is not guaranteed for all systems.

# tcpdump
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
16:15:05.051896 IP blog.ssh > 10.0.3.1.32855: Flags [P.], seq 2546456553:2546456749, ack 1824683693, win 355, options [nop,nop,TS val 620879437 ecr 620879348], length 196

You can specify the interface by using the -i flag followed by the interface name. On most linux systems a special interface name of any can be used to tell tcpdump to listen on all interfaces, I find this extremely useful when troubleshooting servers with multiple interfaces. This is especially true when there are routing issues involved.

# tcpdump -i any
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
16:45:59.312046 IP blog.ssh > 10.0.3.1.32855: Flags [P.], seq 2547763641:2547763837, ack 1824693949, win 355, options [nop,nop,TS val 621343002 ecr 621342962], length 196

Writing to a file

# tcpdump -w /path/to/file

When you just run tcpdump by itself it will output to your screen.

# tcpdump
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
16:15:05.051896 IP blog.ssh > 10.0.3.1.32855: Flags [P.], seq 2546456553:2546456749, ack 1824683693, win 355, options [nop,nop,TS val 620879437 ecr 620879348], length 196

There are many times where you may want to save the tcpdump data to a file, the easiest way to do this is to use the -w flag. This is useful for situations where you may need to save the network dump to review later. One benefit to saving the data to a file is that you can read the dump file multiple times and apply other flags or filters (which we will cover below) to that snapshot of network traffic.

# tcpdump -w /var/tmp/tcpdata.pcap
tcpdump: listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
1 packet captured
2 packets received by filter
0 packets dropped by kernel

By default the data is buffered and will not usually be written to the file until you CTRL+C out of the running tcpdump command.

Reading from a file

# tcpdump -r /path/to/file

Once you save the output to a file you will inherently need to read that file. To do this you can simply use the -r flag followed by the path to the file.

# tcpdump -r /var/tmp/tcpdata.pcap
reading from file /var/tmp/tcpdata.pcap, link-type EN10MB (Ethernet)
16:56:01.610473 IP blog.ssh > 10.0.3.1.32855: Flags [P.], seq 2547766673:2547766805, ack 1824696181, win 355, options [nop,nop,TS val 621493577 ecr 621493478], length 132

As a quick note, if you are more familiar with tools such as wireshark you can read files saved by tcpdump with most network troubleshooting tools like wireshark.

Specifying the capture size of each packet

# tcpdump -s 100

By default most newer implementations of tcpdump will capture 65535 bytes, however in some situations you may not want to capture the default packet length. You can use -s to specify the "snaplen" or "snapshot length" that you want tcpdump to capture.

Specifying the number of packets to capture

# tcpdump -c 10

When you run tcpdump by itself it will keep running until you hit CTRL+C to quit.

# tcpdump host google.com
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes
^C
0 packets captured
4 packets received by filter
0 packets dropped by kernel

You can tell tcpdump to stop capturing after a certain number of packets by using the -c flag followed by the number of packets to capture. This is pretty useful for situations where you may not want tcpdump to spew output to your screen so fast you can't read it, however generally this is more useful when you are using filters to grab specific traffic.

Pulling the basics together

# tcpdump -nvvv -i any -c 100 -s 100

All of the basic flags that were covered above can also be combined to allow you to specify exactly what you want tcpdump to provide.

# tcpdump -w /var/tmp/tcpdata.pcap -i any -c 10 -vvv
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
10 packets captured
10 packets received by filter
0 packets dropped by kernel
# tcpdump -r /var/tmp/tcpdata.pcap -nvvv -c 5
reading from file /var/tmp/tcpdata.pcap, link-type LINUX_SLL (Linux cooked)
17:35:14.465902 IP (tos 0x10, ttl 64, id 5436, offset 0, flags [DF], proto TCP (6), length 104)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1b51 (incorrect -> 0x72bc), seq 2547781277:2547781329, ack 1824703573, win 355, options [nop,nop,TS val 622081791 ecr 622081775], length 52
17:35:14.466007 IP (tos 0x10, ttl 64, id 52193, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.32855 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x4950), seq 1, ack 52, win 541, options [nop,nop,TS val 622081791 ecr 622081791], length 0
17:35:14.470239 IP (tos 0x10, ttl 64, id 5437, offset 0, flags [DF], proto TCP (6), length 168)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1b91 (incorrect -> 0x98c3), seq 52:168, ack 1, win 355, options [nop,nop,TS val 622081792 ecr 622081791], length 116
17:35:14.470370 IP (tos 0x10, ttl 64, id 52194, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.32855 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x48da), seq 1, ack 168, win 541, options [nop,nop,TS val 622081792 ecr 622081792], length 0
17:35:15.464575 IP (tos 0x10, ttl 64, id 5438, offset 0, flags [DF], proto TCP (6), length 104)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1b51 (incorrect -> 0xc3ba), seq 168:220, ack 1, win 355, options [nop,nop,TS val 622082040 ecr 622081792], length 52

Filters

Now that we have covered some of the basic flags we should cover filtering. tcpdump has the ability to filter the capture or output based on a variety of expressions, in this article I am only going to cover a few quick examples to give you an idea of the syntax. For a full list you can checkout the pcap-filter section of the tcpdump manpage.

Searching for traffic to and from a specific host

# tcpdump -nvvv -i any -c 3 host 10.0.3.1

The above command will run a tcpdump and send the output to the screen like we saw with the flags before, however it will only do so if the source or destination IP address is 10.0.3.1. Essentially by adding host 10.0.3.1 we are asking tcpdump to filter out anything that is not to or from 10.0.3.1.

# tcpdump -nvvv -i any -c 3 host 10.0.3.1
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
17:54:15.067496 IP (tos 0x10, ttl 64, id 5502, offset 0, flags [DF], proto TCP (6), length 184)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1ba1 (incorrect -> 0x9f75), seq 2547785621:2547785753, ack 1824705637, win 355, options [nop,nop,TS val 622366941 ecr 622366923], length 132
17:54:15.067613 IP (tos 0x10, ttl 64, id 52315, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.32855 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x7c34), seq 1, ack 132, win 540, options [nop,nop,TS val 622366941 ecr 622366941], length 0
17:54:15.075230 IP (tos 0x10, ttl 64, id 5503, offset 0, flags [DF], proto TCP (6), length 648)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1d71 (incorrect -> 0x3443), seq 132:728, ack 1, win 355, options [nop,nop,TS val 622366943 ecr 622366941], length 596

Only show traffic where the source is a specific host

# tcpdump -nvvv -i any -c 3 src host 10.0.3.1

Where the previous example showed traffic to and from 10.0.3.1 the above command will only show traffic where the source of the packet is 10.0.3.1. This is accomplished by adding src in front of the host filter. This is an additional filter that tells tcpdump to look for a specific "source". This can be reversed by using the dst filter, which specifies the "destination".

# tcpdump -nvvv -i any -c 3 src host 10.0.3.1
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
17:57:12.194902 IP (tos 0x10, ttl 64, id 52357, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.32855 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x1707), seq 1824706545, ack 2547787717, win 540, options [nop,nop,TS val 622411223 ecr 622411223], length 0
17:57:12.196288 IP (tos 0x10, ttl 64, id 52358, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.32855 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x15c5), seq 0, ack 325, win 538, options [nop,nop,TS val 622411223 ecr 622411223], length 0
17:57:12.197677 IP (tos 0x10, ttl 64, id 52359, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.32855 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x1491), seq 0, ack 633, win 536, options [nop,nop,TS val 622411224 ecr 622411224], length 0
# tcpdump -nvvv -i any -c 3 dst host 10.0.3.1
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
17:59:37.266838 IP (tos 0x10, ttl 64, id 5552, offset 0, flags [DF], proto TCP (6), length 184)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1ba1 (incorrect -> 0x586d), seq 2547789725:2547789857, ack 1824707577, win 355, options [nop,nop,TS val 622447491 ecr 622447471], length 132
17:59:37.267850 IP (tos 0x10, ttl 64, id 5553, offset 0, flags [DF], proto TCP (6), length 392)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1c71 (incorrect -> 0x462e), seq 132:472, ack 1, win 355, options [nop,nop,TS val 622447491 ecr 622447491], length 340
17:59:37.268606 IP (tos 0x10, ttl 64, id 5554, offset 0, flags [DF], proto TCP (6), length 360)
    10.0.3.246.22 > 10.0.3.1.32855: Flags [P.], cksum 0x1c51 (incorrect -> 0xf469), seq 472:780, ack 1, win 355, options [nop,nop,TS val 622447491 ecr 622447491], length 308

Filtering source and destination ports

# tcpdump -nvvv -i any -c 3 port 22 and port 60738

You can add some rather complicated filtering statements with tcpdump when you start to using operators like and. You can think of this as something similar to if statements. In this example we are using the and operator to tell tcpdump to only output packets that have both ports 22 and 60738. This allows us to narrow down the packets to a specific session, this can be extremely useful when troubleshooting network issues.

# tcpdump -nvvv -i any -c 3 port 22 and port 60738
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
18:05:54.069403 IP (tos 0x10, ttl 64, id 64401, offset 0, flags [DF], proto TCP (6), length 104)
    10.0.3.1.60738 > 10.0.3.246.22: Flags [P.], cksum 0x1b51 (incorrect -> 0x5b3c), seq 917414532:917414584, ack 1550997318, win 353, options [nop,nop,TS val 622541691 ecr 622538903], length 52
18:05:54.072963 IP (tos 0x10, ttl 64, id 13601, offset 0, flags [DF], proto TCP (6), length 184)
    10.0.3.246.22 > 10.0.3.1.60738: Flags [P.], cksum 0x1ba1 (incorrect -> 0xb0b1), seq 1:133, ack 52, win 355, options [nop,nop,TS val 622541692 ecr 622541691], length 132
18:05:54.073080 IP (tos 0x10, ttl 64, id 64402, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.60738 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0x1e3b), seq 52, ack 133, win 353, options [nop,nop,TS val 622541692 ecr 622541692], length 0

You can express the and operator in a couple of different ways, you can use and or &&. Personally, I tend to use them both; it is important to remember that if you are going to use && that you should enclose the filter expression with single or double quotes. In BASH you can use && to run one command and if successful run a second. In general it is best to simply wrap filter expressions in quotes; this will prevent any unexpected results as filters can have quite a few special characters.

# tcpdump -nvvv -i any -c 3 'port 22 && port 60738'
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
18:06:16.062818 IP (tos 0x10, ttl 64, id 64405, offset 0, flags [DF], proto TCP (6), length 88)
    10.0.3.1.60738 > 10.0.3.246.22: Flags [P.], cksum 0x1b41 (incorrect -> 0x776c), seq 917414636:917414672, ack 1550997518, win 353, options [nop,nop,TS val 622547190 ecr 622541776], length 36
18:06:16.065567 IP (tos 0x10, ttl 64, id 13603, offset 0, flags [DF], proto TCP (6), length 120)
    10.0.3.246.22 > 10.0.3.1.60738: Flags [P.], cksum 0x1b61 (incorrect -> 0xaf2d), seq 1:69, ack 36, win 355, options [nop,nop,TS val 622547191 ecr 622547190], length 68
18:06:16.065696 IP (tos 0x10, ttl 64, id 64406, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.60738 > 10.0.3.246.22: Flags [.], cksum 0x1b1d (incorrect -> 0xf264), seq 36, ack 69, win 353, options [nop,nop,TS val 622547191 ecr 622547191], length 0

Searching for traffic on one port or another

# tcpdump -nvvv -i any -c 20 'port 80 or port 443'

You can also use the or or || operator to filter tcpdump results. In this example we are using the or operator to capture traffic to and from port 80 or port 443. This example is especially useful as webservers generally have two ports open, 80 for http traffic and 443 for https.

# tcpdump -nvvv -i any -c 20 'port 80 or port 443'
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
18:24:28.817940 IP (tos 0x0, ttl 64, id 39930, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.1.50524 > 10.0.3.246.443: Flags [S], cksum 0x1b25 (incorrect -> 0x8611), seq 3836995553, win 29200, options [mss 1460,sackOK,TS val 622820379 ecr 0,nop,wscale 7], length 0
18:24:28.818052 IP (tos 0x0, ttl 64, id 0, offset 0, flags [DF], proto TCP (6), length 40)
    10.0.3.246.443 > 10.0.3.1.50524: Flags [R.], cksum 0x012c (correct), seq 0, ack 3836995554, win 0, length 0
18:24:32.721330 IP (tos 0x0, ttl 64, id 48510, offset 0, flags [DF], proto TCP (6), length 475)
    10.0.3.1.60374 > 10.0.3.246.80: Flags [P.], cksum 0x1cc4 (incorrect -> 0x3a4e), seq 580573019:580573442, ack 1982754038, win 237, options [nop,nop,TS val 622821354 ecr 622815632], length 423
18:24:32.721465 IP (tos 0x0, ttl 64, id 1266, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.246.80 > 10.0.3.1.60374: Flags [.], cksum 0x1b1d (incorrect -> 0x45d7), seq 1, ack 423, win 243, options [nop,nop,TS val 622821355 ecr 622821354], length 0
18:24:32.722098 IP (tos 0x0, ttl 64, id 1267, offset 0, flags [DF], proto TCP (6), length 241)
    10.0.3.246.80 > 10.0.3.1.60374: Flags [P.], cksum 0x1bda (incorrect -> 0x855c), seq 1:190, ack 423, win 243, options [nop,nop,TS val 622821355 ecr 622821354], length 189
18:24:32.722232 IP (tos 0x0, ttl 64, id 48511, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.60374 > 10.0.3.246.80: Flags [.], cksum 0x1b1d (incorrect -> 0x4517), seq 423, ack 190, win 245, options [nop,nop,TS val 622821355 ecr 622821355], length 0

Searching for traffic on two specific ports and from a specific host

# tcpdump -nvvv -i any -c 20 '(port 80 or port 443) and host 10.0.3.169'

While the previous example is great for looking at issues for a multiport protocol; what if this is a very high traffic webserver? The output from tcpdump may get a bit confusing. We can narrow down the results even further by adding a host filter. To do this while maintaining our or expression we can simply wrap the or statement in parenthesis.

# tcpdump -nvvv -i any -c 20 '(port 80 or port 443) and host 10.0.3.169'
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
18:38:05.551194 IP (tos 0x0, ttl 64, id 63169, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.169.33786 > 10.0.3.246.443: Flags [S], cksum 0x1bcd (incorrect -> 0x0d96), seq 4173164403, win 29200, options [mss 1460,sackOK,TS val 623024562 ecr 0,nop,wscale 7], length 0
18:38:05.551310 IP (tos 0x0, ttl 64, id 0, offset 0, flags [DF], proto TCP (6), length 40)
    10.0.3.246.443 > 10.0.3.169.33786: Flags [R.], cksum 0xa64a (correct), seq 0, ack 4173164404, win 0, length 0
18:38:05.717130 IP (tos 0x0, ttl 64, id 51574, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.169.35629 > 10.0.3.246.80: Flags [S], cksum 0x1bcd (incorrect -> 0xdf7c), seq 1068257453, win 29200, options [mss 1460,sackOK,TS val 623024603 ecr 0,nop,wscale 7], length 0
18:38:05.717255 IP (tos 0x0, ttl 64, id 0, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.246.80 > 10.0.3.169.35629: Flags [S.], cksum 0x1bcd (incorrect -> 0xed80), seq 2992472447, ack 1068257454, win 28960, options [mss 1460,sackOK,TS val 623024603 ecr 623024603,nop,wscale 7], length 0
18:38:05.717474 IP (tos 0x0, ttl 64, id 51575, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.169.35629 > 10.0.3.246.80: Flags [.], cksum 0x1bc5 (incorrect -> 0x8c87), seq 1, ack 1, win 229, options [nop,nop,TS val 623024604 ecr 623024603], length 0

You can use the parenthesis multiple times in a single filter, for example the below command will filter the capture to only packets that are to or from port 80 or port 443 and from hosts 10.0.3.169 and 10.0.3.1 if they are destined for 10.0.3.246.

# tcpdump -nvvv -i any -c 20 '((port 80 or port 443) and (host 10.0.3.169 or host 10.0.3.1)) and dst host 10.0.3.246'
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
18:53:30.349306 IP (tos 0x0, ttl 64, id 52641, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.1.35407 > 10.0.3.246.80: Flags [S], cksum 0x1b25 (incorrect -> 0x4890), seq 3026316656, win 29200, options [mss 1460,sackOK,TS val 623255761 ecr 0,nop,wscale 7], length 0
18:53:30.349558 IP (tos 0x0, ttl 64, id 52642, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.35407 > 10.0.3.246.80: Flags [.], cksum 0x1b1d (incorrect -> 0x3454), seq 3026316657, ack 3657995297, win 229, options [nop,nop,TS val 623255762 ecr 623255762], length 0
18:53:30.354056 IP (tos 0x0, ttl 64, id 52643, offset 0, flags [DF], proto TCP (6), length 475)
    10.0.3.1.35407 > 10.0.3.246.80: Flags [P.], cksum 0x1cc4 (incorrect -> 0x10c2), seq 0:423, ack 1, win 229, options [nop,nop,TS val 623255763 ecr 623255762], length 423
18:53:30.354682 IP (tos 0x0, ttl 64, id 52644, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.1.35407 > 10.0.3.246.80: Flags [.], cksum 0x1b1d (incorrect -> 0x31e6), seq 423, ack 190, win 237, options [nop,nop,TS val 623255763 ecr 623255763], length 0

Understanding the output

Capturing network traffic with tcpdump is hard enough with all of the options, but once you have that data you have to decipher it. In this section we are going to cover how to identify the source/destination IP, source/destination Port and the type of packet for the TCP protocol. While these are all very basic items they are far from the extent of what you can identify from tcpdump, however this article is meant to be quick and dirty so we will keep it to the basics. For more information on tcpdump and what is being listed I suggest checking out the manpages.

Identifying the source and destination

Identifying the source and destination addresses and ports are actually fairly easy.

10.0.3.246.56894 > 192.168.0.92.22: Flags [S], cksum 0xcf28 (incorrect -> 0x0388), seq 682725222, win 29200, options [mss 1460,sackOK,TS val 619989005 ecr 0,nop,wscale 7], length 0

Given the above output we can see that the source ip is 10.0.3.246 the source port is 56894 and the destination ip is 192.168.0.92 with a destination port of 22. This is pretty easy to identify once you understand the format of tcpdump. If you haven't guessed the format yet you can break it down as follows src-ip.src-port > dest-ip.dest-port: Flags[S] the source is in front of the > and the destination is behind. You can think of the > as an arrow pointing to the destination.

Identifying the type of packet

10.0.3.246.56894 > 192.168.0.92.22: Flags [S], cksum 0xcf28 (incorrect -> 0x0388), seq 682725222, win 29200, options [mss 1460,sackOK,TS val 619989005 ecr 0,nop,wscale 7], length 0

From the sample above we can tell that the packet is a single SYN packet. We can identify this by the Flags [S] section of the tcpdump output, different types of packets have different types of flags. Without going too deep into what types of packets exist within TCP you can use the below as a cheat sheet for identifying packet types.

  • [S] - SYN (Start Connection)
  • [.] - No Flag Set
  • [P] - PSH (Push Data)
  • [F] - FIN (Finish Connection)
  • [R] - RST (Reset Connection)

Depending on the version and output of tcpdump you may also see flags such as [S.] this is used to indicate a SYN-ACK packet.

An unhealthy example

15:15:43.323412 IP (tos 0x0, ttl 64, id 51051, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.246.56894 > 192.168.0.92.22: Flags [S], cksum 0xcf28 (incorrect -> 0x0388), seq 682725222, win 29200, options [mss 1460,sackOK,TS val 619989005 ecr 0,nop,wscale 7], length 0
15:15:44.321444 IP (tos 0x0, ttl 64, id 51052, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.246.56894 > 192.168.0.92.22: Flags [S], cksum 0xcf28 (incorrect -> 0x028e), seq 682725222, win 29200, options [mss 1460,sackOK,TS val 619989255 ecr 0,nop,wscale 7], length 0
15:15:46.321610 IP (tos 0x0, ttl 64, id 51053, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.246.56894 > 192.168.0.92.22: Flags [S], cksum 0xcf28 (incorrect -> 0x009a), seq 682725222, win 29200, options [mss 1460,sackOK,TS val 619989755 ecr 0,nop,wscale 7], length 0

The above sampling shows an example of an unhealthy exchange, and by unhealthy exchange for this example that means no exchange. In the above sample we can see that 10.0.3.246 is sending a SYN packet to host 192.168.0.92 however we never see a response from host 192.168.0.92.

A healthy example

15:18:25.716453 IP (tos 0x10, ttl 64, id 53344, offset 0, flags [DF], proto TCP (6), length 60)
    10.0.3.246.34908 > 192.168.0.110.22: Flags [S], cksum 0xcf3a (incorrect -> 0xc838), seq 1943877315, win 29200, options [mss 1460,sackOK,TS val 620029603 ecr 0,nop,wscale 7], length 0
15:18:25.716777 IP (tos 0x0, ttl 63, id 0, offset 0, flags [DF], proto TCP (6), length 60)
    192.168.0.110.22 > 10.0.3.246.34908: Flags [S.], cksum 0x594a (correct), seq 4001145915, ack 1943877316, win 5792, options [mss 1460,sackOK,TS val 18495104 ecr 620029603,nop,wscale 2], length 0
15:18:25.716899 IP (tos 0x10, ttl 64, id 53345, offset 0, flags [DF], proto TCP (6), length 52)
    10.0.3.246.34908 > 192.168.0.110.22: Flags [.], cksum 0xcf32 (incorrect -> 0x9dcc), ack 1, win 229, options [nop,nop,TS val 620029603 ecr 18495104], length 0

A healthy example would look like the above, in the above we can see a standard TCP 3-way handshake. The first packet above is a SYN packet from host 10.0.3.246 to host 192.168.0.110, the second packet is a SYN-ACK from host 192.168.0.110 acknowledging the SYN. The final packet is a ACK or rather a SYN-ACK-ACK from host 10.0.3.246 acknowledging that it has received the SYN-ACK. From this point on there is an established TCP/IP connection.

Packet Inspection

Printing packet data in Hex and ASCII

# tcpdump -nvvv -i any -c 1 -XX 'port 80 and host 10.0.3.1'

A common method of troubleshooting application issues over the network is by using tcpdump to use the -XX flag to print the packet data in hex and ascii. This is a pretty helpful command, it allows you to look at both the source, destination, type of packet and the packet itself. However, I am not a fan of this output. I think it is a bit hard to read.

# tcpdump -nvvv -i any -c 1 -XX 'port 80 and host 10.0.3.1'
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
19:51:15.697640 IP (tos 0x0, ttl 64, id 54313, offset 0, flags [DF], proto TCP (6), length 483)
    10.0.3.1.45732 > 10.0.3.246.80: Flags [P.], cksum 0x1ccc (incorrect -> 0x2ce8), seq 3920159713:3920160144, ack 969855140, win 245, options [nop,nop,TS val 624122099 ecr 624117334], length 431
        0x0000:  0000 0001 0006 fe0a e2d1 8785 0000 0800  ................
        0x0010:  4500 01e3 d429 4000 4006 49f5 0a00 0301  E....)@.@.I.....
        0x0020:  0a00 03f6 b2a4 0050 e9a8 e3e1 39ce d0a4  .......P....9...
        0x0030:  8018 00f5 1ccc 0000 0101 080a 2533 58f3  ............%3X.
        0x0040:  2533 4656 4745 5420 2f73 6f6d 6570 6167  %3FVGET./somepag
        0x0050:  6520 4854 5450 2f31 2e31 0d0a 486f 7374  e.HTTP/1.1..Host
        0x0060:  3a20 3130 2e30 2e33 2e32 3436 0d0a 436f  :.10.0.3.246..Co
        0x0070:  6e6e 6563 7469 6f6e 3a20 6b65 6570 2d61  nnection:.keep-a
        0x0080:  6c69 7665 0d0a 4361 6368 652d 436f 6e74  live..Cache-Cont
        0x0090:  726f 6c3a 206d 6178 2d61 6765 3d30 0d0a  rol:.max-age=0..
        0x00a0:  4163 6365 7074 3a20 7465 7874 2f68 746d  Accept:.text/htm
        0x00b0:  6c2c 6170 706c 6963 6174 696f 6e2f 7868  l,application/xh
        0x00c0:  746d 6c2b 786d 6c2c 6170 706c 6963 6174  tml+xml,applicat
        0x00d0:  696f 6e2f 786d 6c3b 713d 302e 392c 696d  ion/xml;q=0.9,im
        0x00e0:  6167 652f 7765 6270 2c2a 2f2a 3b71 3d30  age/webp,*/*;q=0
        0x00f0:  2e38 0d0a 5573 6572 2d41 6765 6e74 3a20  .8..User-Agent:.
        0x0100:  4d6f 7a69 6c6c 612f 352e 3020 284d 6163  Mozilla/5.0.(Mac
        0x0110:  696e 746f 7368 3b20 496e 7465 6c20 4d61  intosh;.Intel.Ma
        0x0120:  6320 4f53 2058 2031 305f 395f 3529 2041  c.OS.X.10_9_5).A
        0x0130:  7070 6c65 5765 624b 6974 2f35 3337 2e33  ppleWebKit/537.3
        0x0140:  3620 284b 4854 4d4c 2c20 6c69 6b65 2047  6.(KHTML,.like.G
        0x0150:  6563 6b6f 2920 4368 726f 6d65 2f33 382e  ecko).Chrome/38.
        0x0160:  302e 3231 3235 2e31 3031 2053 6166 6172  0.2125.101.Safar
        0x0170:  692f 3533 372e 3336 0d0a 4163 6365 7074  i/537.36..Accept
        0x0180:  2d45 6e63 6f64 696e 673a 2067 7a69 702c  -Encoding:.gzip,
        0x0190:  6465 666c 6174 652c 7364 6368 0d0a 4163  deflate,sdch..Ac
        0x01a0:  6365 7074 2d4c 616e 6775 6167 653a 2065  cept-Language:.e
        0x01b0:  6e2d 5553 2c65 6e3b 713d 302e 380d 0a49  n-US,en;q=0.8..I
        0x01c0:  662d 4d6f 6469 6669 6564 2d53 696e 6365  f-Modified-Since
        0x01d0:  3a20 5375 6e2c 2031 3220 4f63 7420 3230  :.Sun,.12.Oct.20
        0x01e0:  3134 2031 393a 3430 3a32 3020 474d 540d  14.19:40:20.GMT.
        0x01f0:  0a0d 0a                                  ...

Printing packet data in ASCII only

# tcpdump -nvvv -i any -c 1 -A 'port 80 and host 10.0.3.1'

I tend to prefer to print only the ASCII data, this helps me to quickly identify what is being sent and what is correct or not correct about the packets data. To print packet data in only the ascii format you can use the -A flag.

# tcpdump -nvvv -i any -c 1 -A 'port 80 and host 10.0.3.1'
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
19:59:52.011337 IP (tos 0x0, ttl 64, id 53757, offset 0, flags [DF], proto TCP (6), length 406)
    10.0.3.1.46172 > 10.0.3.246.80: Flags [P.], cksum 0x1c7f (incorrect -> 0xead1), seq 1552520173:1552520527, ack 428165415, win 237, options [nop,nop,TS val 624251177 ecr 624247749], length 354
E.....@.@.Ln
...
....\.P\.....I'...........
%5Q)%5C.GET /newpage HTTP/1.1
Host: 10.0.3.246
Connection: keep-alive
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,image/webp,*/*;q=0.8
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_9_5) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/38.0.2125.101 Safari/537.36
Accept-Encoding: gzip,deflate,sdch
Accept-Language: en-US,en;q=0.8

As you can see from the output above we have successfully captured an http GET request. Being able to print the packet data in a human readable format is very useful when troubleshooting application issues where the traffic is not encrypted. If you are troubleshooting encrypted traffic then printing packet data is not very useful. However, if you use have the certificates in use you could use commands such as ssldump or even wireshark.

Non-TCP Traffic

While the majority of this article covered TCP based traffic tcpdump can capture much more than TCP. It can also be used to capture ICMP, UDP, and ARP packets to name a few. Below are a few quick examples of non-TCP packets captured by tcpdump.

ICMP packets

# tcpdump -nvvv -i any -c 2 icmp
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
20:11:24.627824 IP (tos 0x0, ttl 64, id 0, offset 0, flags [DF], proto ICMP (1), length 84)
    10.0.3.169 > 10.0.3.246: ICMP echo request, id 15683, seq 1, length 64
20:11:24.627926 IP (tos 0x0, ttl 64, id 31312, offset 0, flags [none], proto ICMP (1), length 84)
    10.0.3.246 > 10.0.3.169: ICMP echo reply, id 15683, seq 1, length 64

UDP packets

# tcpdump -nvvv -i any -c 2 udp
tcpdump: listening on any, link-type LINUX_SLL (Linux cooked), capture size 65535 bytes
20:12:41.726355 IP (tos 0xc0, ttl 64, id 0, offset 0, flags [DF], proto UDP (17), length 76)
    10.0.3.246.123 > 198.55.111.50.123: [bad udp cksum 0x43a9 -> 0x7043!] NTPv4, length 48
        Client, Leap indicator: clock unsynchronized (192), Stratum 2 (secondary reference), poll 6 (64s), precision -22
        Root Delay: 0.085678, Root dispersion: 57.141830, Reference-ID: 199.102.46.75
          Reference Timestamp:  3622133515.811991035 (2014/10/12 20:11:55)
          Originator Timestamp: 3622133553.828614115 (2014/10/12 20:12:33)
          Receive Timestamp:    3622133496.748308420 (2014/10/12 20:11:36)
          Transmit Timestamp:   3622133561.726278364 (2014/10/12 20:12:41)
            Originator - Receive Timestamp:  -57.080305658
            Originator - Transmit Timestamp: +7.897664248
20:12:41.748948 IP (tos 0x0, ttl 54, id 9285, offset 0, flags [none], proto UDP (17), length 76)
    198.55.111.50.123 > 10.0.3.246.123: [udp sum ok] NTPv4, length 48
        Server, Leap indicator:  (0), Stratum 3 (secondary reference), poll 6 (64s), precision -20
        Root Delay: 0.054077, Root dispersion: 0.058944, Reference-ID: 216.229.0.50
          Reference Timestamp:  3622132887.136984840 (2014/10/12 20:01:27)
          Originator Timestamp: 3622133561.726278364 (2014/10/12 20:12:41)
          Receive Timestamp:    3622133618.830113530 (2014/10/12 20:13:38)
          Transmit Timestamp:   3622133618.830129086 (2014/10/12 20:13:38)
            Originator - Receive Timestamp:  +57.103835195
            Originator - Transmit Timestamp: +57.103850722

If you have an awesome tcpdump command example that you think should be added to this article feel free to post it in the comments section.


Originally Posted on BenCane.com: Go To Article

Written by Benjamin Cane

October 13th, 2014 at 8:50 am

Posted in Uncategorized

Hacker News thread on PDF reporting tools

without comments

By Vasudev Ram

I saw this thread about PDF reporting tools on Hacker News (HN) today:

Ask HN: What do you use for PDF reports these days?

It was interesting to see that multiple HN users commented saying that they use ReportLab for PDF report creation in Python and like it a lot. I also commented, mentioning my xtopdf PDF generation library, which is also written in Python and builds on top of Reportlab, and provides a subset of ReportLab's functionality, with a somewhat easier interface / API for that subset.


PrinceXML (*), Jasper (Java), JagPDF (C++, Python, Java, C), Flying Saucer (Java), PDFBox (Java), prawn (Ruby), wkhtmltopdf, FPDF/TCPDF (PHP) were some of the other interesting PDF creation tools or libraries mentioned. I have come across many of these tools in my explorations of the PDF creation field (which has been going on for some years, as it is a personal interest of mine, and I've also done some consulting projects that involved PDF generation and PDF text extraction), but still came across some tools new to me, in the HN thread.

(*) A possibly somewhat less-known fact is that Håkon Wium Lie, one of the board members of YesLogic, the company behind PrinceXML is also the original proposer of CSS and the CTO of Opera Software (yes, the company behind the Opera browser).

Wikipedia page about PDF - the Portable Document Format.

PDF became an ISO standard - ISO 32000-1 some years ago.

- Vasudev Ram - Dancing Bison Enterprises

Click here to signup for email notifications about new products and services from Vasudev Ram.

Contact Page

Written by Vasudev Ram

October 12th, 2014 at 3:19 pm

Installing Citrix on Fedora 21

without comments

Time moves on. Distros move on, and so again it’s time to install Citrix Receiver for Linux. They have moved on to version 13.1, which fixes a lot of install bugs in the Ubuntu version. Unfortunately that seems to be at the cost of the RPM version which is no longer available. In this post we will be installing it on Fedora 21 which is still in beta.

Get the software Receiver for Linux 13.1 and look for For 64-bit Systems (assuming you have a 64 -bit system).

uname -p
-p, –processor print the processor type or “unknown”
$ uname -p
x86_64

Then look for File Type: .tar.gz and download it. As root move it to somewhere like /usr/local/src/citrix/. Make sure you create a new directory as it is a tarbomb. Then extract it using the following command:

tar xvf linuxx64-13.1.0.285639.tar.gz

You can install it using the command:

# ./setupwfc
Citrix Receiver for Linux 13.1.0 setup.

Copyright 1996-2014 Citrix Systems, Inc. All rights reserved.
Copyright (c) 1986-1997 RSA Security, Inc. All rights reserved.
This software uses libraries from the FFmpeg project under the LGPLv2.1

Citrix, Independent Computing Architecture (ICA), Program Neighborhood,
MetaFrame, and MetaFrame XP are registered trademarks and Citrix Receiver,
Citrix XenApp, XenDesktop, Citrix Presentation Server, Citrix Access Suite,
and SpeedScreen are trademarks of Citrix Systems, Inc. in the United States
and other countries.

Microsoft, MS, MS-DOS, Outlook, Windows, Windows NT, and BackOffice are
either registered trademarks or trademarks of Microsoft Corporation in
the United States and other countries.

All other Trade Names referred to are the Servicemark, Trademark,
or Registered Trademark of the respective manufacturers.


Select a setup option:

 1. Install Citrix Receiver for Linux 13.1.0
 2. Remove Citrix Receiver for Linux 13.1.0
 3. Quit Citrix Receiver for Linux 13.1.0 setup

Enter option number 1-3 [1]: 1

Please enter the directory in which Citrix Receiver for Linux is to be installed.
[default /opt/Citrix/ICAClient]
or type "quit" to abandon the installation:

The parent directory /opt/Citrix does not exist.
Do you want to create it? [default y]: y

You have chosen to install Citrix Receiver for Linux 13.1.0 in /opt/Citrix/ICAClient.

Proceed with installation? [default n]: y

Installation proceeding...

Checking available disk space ...

        Disk space available 230130076 K
        Disk space required 35519 K


Continuing ...
Creating directory /opt/Citrix/ICAClient
Core package...
Setting file permissions...
Integrating with browsers...
Browsers found.

Integration complete.
Do you want to integrate Citrix Receiver with KDE and GNOME? [default y]: y
Do you want GStreamer to use the plugin from this client? [default y]:
Do you want to install USB support? [default n]: n
USB support not installed.

Select a setup option:

 1. Install Citrix Receiver for Linux 13.1.0
 2. Remove Citrix Receiver for Linux 13.1.0
 3. Quit Citrix Receiver for Linux 13.1.0 setup

Enter option number 1-3 [3]: 3
Quitting Citrix Receiver for Linux 13.1.0 setup.

Unfortunately we are not out of the woods yet, as a quick check shows that we are missing some dependencies.

# ldd /opt/Citrix/ICAClient/wfica | grep -i "not found"
        libgtk-x11-2.0.so.0 => not found
        libgdk-x11-2.0.so.0 => not found
        libatk-1.0.so.0 => not found
        libgdk_pixbuf-2.0.so.0 => not found

Fortunately with the excellent yum installer we can just point to the missing files and it will install the required packages.

yum install libgtk-x11-2.0.so.0 libgdk-x11-2.0.so.0 libatk-1.0.so.0 libgdk_pixbuf-2.0.so.0

Once you log in to your companies web page and launch citrix you get a popup asking you to accept the license.
Screenshot of the EULA

Citrix ships with a very small number of CA Root Certs. Therefore the chance is quite high that you will be presented with a signed cert from a CA provider that they do not have the root certificate for. If your server has signed their SSL/TSL cert with a missing root certificate you will be presented with the “SSL error 61″ message that we have come to know and love.

SSL Error

At this point I normally suggested using the certs from Firefox, but in the version of Firefox (32.0.2) shipped with Fedora 21 Beta, the root Certs are no longer kept as files on the disk. The error message actually tells you which one you are missing, in my case “Global Sign Root CA”. Now go to Firefox and open Edit > Preferences > Advanced > Certificates > View Certificates > Authorities, where you will be presented with a long list of Authorities.
GlobalSign-AlphaSSLCA-G2.pem from Firefox

Scroll down to the Authority that issued your cert and starting at the top, export them one by one and save them to /opt/Citrix/ICAClient/keystore/cacerts/. I needed to save them in my own Downloads folder, and from there I moved them to the folder as root adding the pem extension.

mv -v /home/user/AlphaSSLCA-G2 /opt/Citrix/ICAClient/keystore/cacerts/GlobalSign-AlphaSSLCA-G2.pem

For me it turned out to be the third one and once I had it installed I was able to open the applications on my companies citrix web page. One improvement is that there is no warning about missing languages.

Written by ken_fallon

October 11th, 2014 at 5:44 am

Posted in citrix,General
